L5087MT270E

Sensor	8K
Image Sensor	CMOS
Shutter	Global
Resolution	8192 × 2
Line Rate	148.8 kHz
Bit Depth	12
Mono/Color	Mono
Pixel Size	7 μm × 7 μm
S/N Ratio	40 dB
Dynamic Range	63.3 dB
Image Format	Mono8/10
Binning	Support
ROI	Support
X Flip	Support
Gain	1~32
Gamma	From 0 to 4, support LUT
Exposure Time	4μS~100mS
Trigger Mode	Software Trigger/Hardware Trigger/Free Run Mode
FPN	Support
TDI Stages	singleLine;two_tdi
User Setting	Support two sets of user-defined configurations
Port	10Gige
GPIO Interface	4 differential input, output, and 1 GPIO input, output,
Lens Mount	M72
Power Supply	DC 12~24V power supply via 12-pin Hirose connector
Power Consumption	14W
Product Dimensions	80mm×80mm×48.2mm(Not including rear case connector)
Net Weight	520 g
Storage Temperature	-30℃~+80℃
Operating Temperature	0℃～+50℃

Description

Binning	Support
Bit depth	12
Dynamic range	63.3 dB
Exposure time	4us~100mS
Fpn	Support
Gain	1~32
Gamma	From 0 to 4，support LUT
Gpio interface	4 differential input, output, and 1 GPIO input, output,
Image format	Mono8/10
Image sensor	CMOS
Lens mount	M72
Line-rate	148.8 kHz
Pixel size	7 um x 7 um
Port	10GigE
Power consumption	14W
Power supply	DC 12~24V power supply via 12-pin Hirose connector
Resolution	8192 x 2
Roi	Support
Sensor	8K
Shutter	Global
Storage temperature	-30℃~+80℃
Trigger mode	Software Trigger/Hardware Trigger/Free Run Mode
User setting	Support two sets of user-defined configurations
X flip	Support
Mono-color	Mono
S/n ratio	40 dB
Tdi stages	singleLine;two_tdi
