L5047CK141E

Sensor	4K
Image Sensor	CMOS
Shutter	Global
Resolution	4096 × 2
Line Rate	92 kHz
Bit Depth	12
Mono/Color	Color
Pixel Size	7 μm × 7 μm
Pixel	4096×2
S/N Ratio	39.4 DB
Dynamic Range	66 dB
Image Format	BayerRG8,RGB8
Binning	Support
ROI	Support
X Flip	Support
Gain	1–32
White Balance	Support
Gamma	From 0 to 4, support LUT
Exposure Time	4 us–100 ms
Trigger Mode	Software Trigger/Hardware Trigger/Free Run Mode
FPN	Support
User Setting	Support two sets of user-defined configurations
Pixel Clock	34/51/64/85 MHz
Port	CameraLink
Lens Mount	M42
Power Supply	12V～24 VDC power supply
Power Consumption	4.5 W
Product Dimensions	62 mm × 62 mm × 33.7 mm (Not including rear case connector)
Net Weight	200 g
Storage Temperature	-30℃~+80℃
Operating Temperature	-30℃~+50℃

Description

Binning	Support
Bit depth	12
Dynamic range	66 dB
Exposure time	4 us-100 ms
Fpn	Support
Gain	1-32
Gamma	From 0 to 4，support LUT
Image format	BayerRG8,RGB8
Image sensor	CMOS
Lens mount	M42
Line-rate	92 kHz
Pixel	4096×2
Pixel size	7 um x 7 um
Port	CameraLink
Power consumption	4.5 W
Power supply	12V~24 VDC power supply
Resolution	4096 x 2
Roi	Support
Sensor	4K
Shutter	Global
Storage temperature	-30℃~+80℃
Trigger mode	Software Trigger/Hardware Trigger/Free Run Mode
User setting	Support two sets of user-defined configurations
White balance	Support
X flip	Support
Mono-color	Color
S/n ratio	39.4 DB
Pixel clock	34/51/64/85 MHz
