Description
| Shutter type | Global shutter |
| Spectrum | SWIR (400 nm to 1700 nm) |
| Lens Mount | C-mount |
| Synchronization | Software trigger, hardware trigger, action command, PTP |
| Data Interface | Gigabit Ethernet 1 Gbps |
| Connector | RJ45 (horizontal locking) | Hirose HR10A-7R-6PB |
| Dimensions [W x H x L] | 40 mm x 40 mm x 43 mm |
| Mass | 116 g |
| Operating Temperature | 0° to 50°C (ambient) |
| Opto-isolated I/O Ports | 1 input, 1 output |
| Power Consumption [Maximum] | 2.9 W |
| Power Requirements | Power over Ethernet (PoE); or 12 V nominal (9.5 – 24 V) |
| Storage Humidity | 30 to 95% (no condensation) |
| Storage Temperature | -30°C to 65°C (ambient) |
| Acquisition Modes | Continuous, Single Frame, Multi Frame |
| Exposure Control | Hardware trigger, programmable via camera API, automatic |
| Exposure Range | 15 µs to 30 seconds |
| Flash Memory | 1 MB non-volatile memory |
| Gain Control | Manual, Automatic (AGC) |
| Image Buffer | 240 MB |
| Image Processing | Gamma, lookup table, and sharpness |
| Partial Image Modes | Decimation, ROI |
| Dynamic Range dB | 57 |
| Gain Range | 0 dB – 42 dB |
| QE (Mono) | 63 |
| Saturation Capacity (e-) | 184780 |
| Temporal Dark Noise (Read Noise) | 256 |
| Port | Gigabit Ethernet Port |
| Required Accessories | SWIR Lens, Cable, Host Adapter (GigE) |
| Compliance | CE, FCC, KCC, RoHS, REACH. ECCN is: US ECCN 6A003.b.4.a / Canadian ECL 1-6.A.3.b.4.a |
