Description
| Shutter type | Rolling shutter |
| Spectrum | Mono |
| Optical Filter | None |
| Lens Mount | S-mount |
| Data Interface | USB 3.1 Micro-B, back connector (USB2 not supported) |
| Connector | USB3 Micro-B (back) | JST BM06B-NSHSS-TBT |
| Dimensions [W x H x L] | 29.5 mm x 29.5 mm x 23 mm |
| Mass | 17 g |
| Operating Temperature | 0° to 50°C (ambient) |
| Power Consumption [Maximum] | 2.4 W |
| Power Requirements | 5 V via USB3 interface |
| Storage Humidity | 20 to 95% (no condensation) |
| Storage Temperature | -30° to 60°C |
| Acquisition Modes | Continuous / Single Frame / Multi Frame |
| Exposure Control | Hardware trigger, programmable via camera API, automatic |
| Exposure Range | 9 µs to 0.5 seconds |
| Flash Memory | 6 MB |
| Gain Control | Manual, automatic (AGC) |
| Image Buffer | 96 MB |
| Image Processing | Gamma, lookup table |
| Partial Image Modes | Pixel binning, ROI |
| Dynamic Range dB | 69 |
| Gain Range | 0 dB to 27 dB |
| Saturation Capacity (e-) | 10080 |
| Temporal Dark Noise (Read Noise) | 3.04 |
| Port | USB3 Port |
| Required Accessories | Lens, Cable, Host Adapter (USB 3.1 Gen 1) |
| Compliance | CE, FCC, RoHS, REACH. The ECCN for this product is: EAR099. |
