Description
| Shutter type | Global shutter |
| Spectrum | Color |
| Optical Filter | IR-Cut Off (670 nm) |
| Lens Mount | CS-mount |
| Synchronization | Software trigger, hardware trigger, action command, PTP |
| Data Interface | Gigabit Ethernet 1 Gbps |
| Connector | RJ45 (horizontal locking) | Hirose HR10A-7R-6PB |
| Dimensions [W x H x L] | 29 mm × 29 mm × 30 mm |
| Mass | 36 g |
| Operating Temperature | 0° to 50°C (ambient) |
| Opto-isolated I/O Ports | 1 input, 1 output |
| Power Consumption [Maximum] | 3 W (2.8 W nominal) |
| Power Requirements | Power over Ethernet (PoE), or 12 V nominal (8 – 24 V) via GPIO |
| Storage Humidity | 30 to 95% (no condensation) |
| Storage Temperature | -30° to 60°C |
| Acquisition Modes | Continuous / Single Frame / Multi Frame |
| Exposure Control | Hardware trigger, programmable via camera API, automatic |
| Exposure Range | 4 µs to 30 seconds |
| Flash Memory | 6 MB non-volatile memory |
| Gain Control | Manual, automatic (AGC) |
| Image Buffer | 240 MB |
| Image Processing | Color correction matrix, gamma, lookup table, saturation, and sharpness |
| Partial Image Modes | Pixel binning, decimation, ROI |
| Dynamic Range dB | 74.29 |
| Gain Range | 0 db to 47 dB |
| Saturation Capacity (e-) | 22346 |
| Temporal Dark Noise (Read Noise) | 3.81 |
| Port | Gigabit Ethernet Port |
| Required Accessories | Lens, Cable, Host Adapter (GigE) |
| Compliance | CE, FCC, KCC, RoHS. The ECCN for this product is: EAR099. |
