Machine vision in focus
| Specification | Value |
|---|---|
| Image circle diameter | 3.4 (mm) |
| Min sensor size | 1/3″ |
| Minimum | 25.0 x 11.0 (mm x mm) |
| Maximum | inf x inf (mm x mm) |
| Angle of view | 60 (deg) |
| Working f/N | 14 |
| Focusing | Manual |
| Light color | white (nm) |
| Supply voltage | 24 (V) |
| Current | 40 (mA) |
| Power consumption | 1.0 (W) |
| Typical pulse voltage | 40 (V) |
| Max pulse current | 100 (mA) |
| Peak power consumption | 4 (W) |
| Max pulse duration | 1 (ms) |
| Max duty-cycle | 1.5 (%) |
| Liquid lens model | – |
| Temperature sensor | – |
| Focal power mode | – |
| Response time | – (ms) |
| Setting time | – (ms) |
| Current range | – (mA) |
| Lifecycles (10%-90% sinusoidal) | – |
| Connector | – |
| Mount | C |
| Phase adjustment | No |
| Total length | 167.1 (mm) |
| Probe length | 159.1 (mm) |
| Probe diameter | 21 (mm) |
| Mass | 111 (g) |
| Operating temperature | 0-40 (°C) |
| Storage temperature | 0-50 (°C) |
| Operating relative humidity | 20-85, non condensing (%) |
| Installation | Indoor use only |
| Risk group according to CEI EN 62471:2010 | Risk group 1 |
| Lens mount | C |
|---|---|
| Power consumption | 1.0 (W) |
| Risk group (cei 62471) | Risk group 1 |
| Operating relative humidity | 20-85, non condensing (%) |
| Max pulse current | 100 (mA) |
| Installation | Indoor use only |
| Storage temperature | 0-50 (°C) |
| Operating temperature | 0-40 (°C) |
| Current | 40 (mA) |
| Supply voltage | 24 (V) |
| Image circle diameter | 3.4 (mm) |
| Mass | 111 (g) |
| Phase adjustment | No |
| Probe diameter | 21 (mm) |
| Accessory developer | Opto |
| Operation power source | |
| Connector | – |
| Working f/N | 14 |
| Focusing | Manual |
| Typical pulse voltage | 40 (V) |
| Probe length | 159.1 (mm) |
| Total length | 167.1 (mm) |
| Light color | white (nm) |
| Angle of view | 60 (deg) |
| Maximum | inf x inf (mm x mm) |
| Minimum | 25.0 x 11.0 (mm x mm) |
| Peak power consumption | 4 (W) |
| Min sensor size | 1/3" |
| Lifecycle (1090% sin) | – |
| Focal power mode | – |
| Temperature sensor | – |
| Liquid lens model | – |
| Max pulse duration | 1 (ms) |
| Max duty cycle | 1.5 (%) |
| Color |
