Description
| Ordernumber (SAP-Number) | 2.200000357E9 |
| Framegrabbe Line | Processing |
| Framegrabbe Series | microEnable |
| processor | Vision Processor |
| On board memory | 2 GByte DDR3-RAM |
| Connectors | 4 x DIN 1.0/2.3 |
| Camera Support | area scan camera,line scan camera |
| Sensor Type | Grayscale sensor,CFA sensor (Bayer),RGB sensor |
| Bit Depth | 8-16-bit (grayscale), 24-48-bit (color) |
| Test Environment | Camera Simulator |
| On-board GPIO interface | 4 opto-coupled inputs (4,5V – 28V), optional 2 opto-coupled differential inputs (RS422),4 opto-coupled outputs (4,5V – 28V),Shaft encoder input, programmable rescaler, multiple-camera synchronization |
| GPIO Interface Summary | 8in/8out (max.), TTL or opto-coupled |
| Basic Features | White Balance,LUT,Offset/Gain/Gamma correction,Invert,Mirroring,ROI,Image Selector |
| Dimensions | PCIe Standard height, half length card: 167.64 mm length x 111.15 mm height |
| Approximate Weight | 168 g |
| Power consumption / Power Source | typ. 1.175 A @ 12V (actual values depend on image pre-processing), maximum load: 3.35 A (single supply over 4-pin power connector) |
| Operating Temperature | 50° (0 LFM*), 60° (100 LFM*) FPGA operating temperature: 0°C to 85°C LFM = Linear Feet per Minute, unit for measuring airflow velocity |
| Storage Temperature | -50°C up to 80°C |
| Relative Humidity (operating, storage) | 5% – 90% non-condensing (operating), 0% – 95% (storage) |
| MTBF | pending |
| Compliances | RoHS,WEEE,REACH |
| Software drivers | Windows 10 / 8 / 7 (32-Bit),Windows 10 / 8 / 7 (64-Bit) |
| Software Tools | microDisplay (Acquisition control and viewer),microDiagnostics (Service tool),GenICam Explorer (Camera configuration tool),SDK,Documentation,Device Drivers |
| Software API | Silicon Software SDK,.net interface |
| FPGA programming | VisualApplets |
| BV-Software Compatibility | Common Vision Blox,Halcon,Cognex |
| Cable length | <40 |
| Flexibility | Customizable |
| Number of Cameras | 4 |
| System Costs | Medium |
For more information about the features, visit the Basler Product Documentation.
