Description
| Max. Aperture Ratio | 1:1.8 |
| Wavelength Range | 400nm – 1700nm |
| Max. Image Circle | φ11.4mm |
| Iris type | Manual |
| Iris | F1.8‐ F16C |
| Focus type | Manual |
| Focus | 0.1m ‐ Inf. |
| Angle of view-1/1.4” (Vertical) | 46.7° |
| Angle of view-1/1.4” (Horizontal) | 56.6° |
| Angle of view-1/1.4” (Diagonal) | 68.7° |
| Effective Lens Aperture | Front: φ28.4mm; Rear: φ15.5mm |
| Filter Size | M46.0 P=0.75mm |
| Dimensions | φ49mm×54.7mm |
| Weight | TBA |
| Operating Temperature | -10℃ ‐ +50℃ |
For more information about the features, visit the Computar Product Documentation.
