LTPRHP3W-W

Specification	Value
Active area diameter	11 (mm)
Light color, peak wavelength	white, 6000 K
Spectral FWHM	– (nm)
Illuminance	30 (klux)
Operating mode	Continuous and strobe
Supply voltage	12-24 (V)
Power consumption	4.5 (W)
LED forward voltage typical (max)	2.8 (-) (V)
Max LED forward current	720 (mA)
Max pulse current	2000 (mA)
Estimated MTBF	> 100000 (hours)
Connector	M8
Cables	CB244P1500 included
Mount	C
Phase adjustment	Yes
Diameter	38.5 (mm)
Length	90.8 (mm)
Mass	153 (g)
Operating temperature	0-40 (°C)
Storage temperature	0-50 (°C)
Operating relative humidity	20-85, non condensing (%)
Installation	Indoor use only
Risk group according to CEI EN 62471:2010	Risk group 2

Description

With a 35 mm lens, F/N 1.4 at 100 mm working distance without projection pattern at maximum driving current. Estimated value.
To pulse LTRPHP3W, models built-in electronics must be bypassed in order to drive the LED directly.
Tolerance ± 10%
At max forward current. Tolerance is ± 0.06V on forward voltage measurements
Max continuous LED driving current is supplied through the built-in electronics. No external controller is required.
At pulse width <= 10 ms and duty cycle <= 10%. Built-in electronics board must be bypassed (see tech info)
At 55 °C, 720mA.

Mount	C
Installation	Indoor use only
Light color, peak wavelength	white, 6000 K
Max pulse current	2000 (mA)
Accessory developer	Opto
Active area diameter	11 (mm)
Mass	153 (g)
Length	90.8 (mm)
Connector	M8
Supply voltage	12-24 (V)
Operating temperature	0-40 (°C)
Storage temperature	0-50 (°C)
Color	white, 6000 K
Operating relative humidity	20-85, non condensing (%)
Phase adjustment	Yes
Risk group (cei 62471)	Risk group 2
Illuminance	30 (klux)
Power consumption	4.5 (W)
Cables	CB244P1500 included
Estimated mtbf	> 100000 (hours)
Led fwd volt (typ/max)	2.8 (-) (V)
Max led forward current	720 (mA)
Operating mode	Continuous and strobe
Diameter	38.5 (mm)
Lens mount	C
