| Synchronization |
Image sync: Free-running, software & hardware trigger, action command | Timestamp Sync: PTP (IEEE1588) |
| Protection |
IP30 |
| Data Interface |
Gigabit Ethernet 1 Gbps |
| Connector |
RJ-45 (vertical & horizontal locking) | HD15 type (female) |
| Digitization Bit Depth (ADC) |
8-bit, 12-bit |
| Dimensions [W x H x L] |
46 mm × 46 mm × 37 mm |
| Mass |
111 g |
| Non-Isolated I/O Ports |
2 RS-422 input, 2 RS-422 output, 1 RS-422 Bi-directional |
| Operating Temperature |
-10°C to 65°C (measured at the front face of the camera) |
| Power Consumption [Maximum] |
5 W |
| Power Requirements |
Power Over Ethernet (PoE) or 12 to 24 V via GPIO connector |
| Storage Humidity |
15 to 85% (no condensation) |
| Storage Temperature |
-20°C to 80°C |
| Acquisition Modes |
Continuous / Single Frame |
| Exposure Control |
Hardware trigger, programmable via camera API |
| Exposure Range |
5 µs to 2500 µs |
| Flash Memory |
32 MB non-volatile memory |
| Gain Control |
Manual |
| Image Buffer |
90 MB |
| Image Processing |
Image Compression (TurboDrive), gamma, lookup table, pixel correction, flat line correction and line spacial correction |
| Partial Image Modes |
Pixel binning, ROI, Muti-ROI |
| Dynamic Range dB |
72 |
| Gain Range |
1x to 10x |
| Peak Wavelength |
R 625 / G 550 / B 470 nm |
| Responsivity |
TBD |
| Port |
Gigabit Ethernet Port |
| Power Sourcing Equipment |
IEEE802.3af-2003 PoE Interface Card / Injector/ Switch or External Camera Power Supply |
| Required Accessories |
Lens, Cable, Host Adapter (GigE) |
| Compliance |
CE, FCC, KCC, RoHS. The ECCN for this product is: EAR099. |
