L5167CPA90

Image Sensor	CMOS
Shutter	Global
Resolution	16384 × 16
Line Rate	92 kHz(1-Line)、45.3 kHz(2-TDI)、23.1 kHz(4-TDI)
Bit Depth	12bit
Mono/Color	Color
Pixel Size	5 μm × 5 μm
S/N Ratio	39.5dB
Dynamic Range	68.5dB
Image Format	RGB8
Binning	Support
ROI	Support
X Flip	Support
Gain	1~32
White Balance	Support
Exposure Time	4μs~100ms
Trigger Mode	Software Trigger/Hardware Trigger/Free Run Mode
FPN	Support
User Setting	Support three sets of user-defined configurations
Port	CXP-12
GPIO Interface	4 differential input,output and 1 GPIO input,output
Lens Mount	M90*1, flange back focus 12 mm; can be transferred to F-mount lens via adapter ring
Power Supply	Powered by 12-pin Hirose interface, DC24V, supports PoCXP
Power Consumption	21W @24 VDC
Product Dimensions	99 mm × 99 mm × 65 mm (Non including rear case connector)
Net Weight	About 930g
Storage Temperature	-30℃~+80℃
Operating Temperature	-30℃~+50℃

Description

Binning	Support
Bit depth	12bit
Dynamic range	68.5dB
Exposure time	4us~100mS
Fpn	Support
Gain	1~32
Gpio interface	4 differential input,output and 1 GPIO input,output
Image format	RGB8
Image sensor	CMOS
Lens mount	M90*1, flange back focus 12 mm; can be transferred to F-mount lens via adapter ring
Line-rate	92 kHz(1-Line)、45.3 kHz(2-TDI)、23.1 kHz(4-TDI)
Pixel size	5 um x 5 um
Port	CXP-12
Power consumption	21W @24 VDC
Power supply	Powered by 12-pin Hirose interface, DC24V, supports PoCXP
Resolution	16384 x 16
Roi	Support
Shutter	Global
Storage temperature	-30℃~+80℃
Trigger mode	Software Trigger/Hardware Trigger/Free Run Mode
User setting	Support three sets of user-defined configurations
White balance	Support
X flip	Support
Mono-color	Color
S/n ratio	39.5dB
