| Sensor | 2K |
| Image Sensor | CMOS |
| Shutter | Global |
| Resolution | 2048 × 1 |
| Line Rate | 49 kHz |
| Bit Depth | 12 |
| Mono/Color | Mono |
| Pixel Size | 14 μm × 14 μm |
| S/N Ratio | >39dB |
| Dynamic Range | 66dB |
| Image Format | Mono8/10/12/10Packed/12Packed |
| ROI | Support |
| X Flip | Support |
| Gain | 1~32 |
| Gamma | From 0 to 4, support LUT |
| Exposure Time | 8μs~100ms |
| Trigger Mode | Software Trigger/Hardware Trigger/Free Run Mode |
| FPN | Support |
| User Setting | Support two sets of user-defined configurations |
| Image Buffer | 64MB image cache, 64MB data cache |
| Port | GigE |
| GPIO Interface | 12-pin Hirose interface for external power supply and external triggering; 2 differential/single-ended inputs, 1 differential configurable input or output, 1 high-speed optocoupler single-ended input, 1 GPIO configurable input or output |
| Lens Mount | M42 x 1 |
| Power Supply | DC 12~24V power supply via 12-pin Hirose connector |
| Power Consumption | ≈4.5W |
| Product Dimensions | 62 mm × 62 mm × 44 mm (Not including rear case connector) |
| Net Weight | 245 g |
| Storage Temperature | -30℃~+80℃ |
| Operating Temperature | 0℃~+50℃ |
| Bit depth | 12 |
|---|---|
| Dynamic range | 66dB |
| Exposure time | 8us~100mS |
| Fpn | Support |
| Gain | 1~32 |
| Gamma | From 0 to 4，support LUT |
| Gpio interface | |
| Image buffer | 64MB image cache，64MB data cache |
| Image format | Mono8/10/12/10Packed/12Packed |
| Image sensor | CMOS |
| Lens mount | M42 x 1 |
| Line-rate | 49 kHz |
| Pixel size | 14 um x 14 um |
| Port | GigE |
| Power consumption | ≈4.5W |
| Power supply | DC 12~24V power supply via 12-pin Hirose connector |
| Resolution | 2048 x 1 |
| Roi | Support |
| Sensor | 2K |
| Shutter | Global |
| Storage temperature | -30℃~+80℃ |
| Trigger mode | Software Trigger/Hardware Trigger/Free Run Mode |
| User setting | Support two sets of user-defined configurations |
| X flip | Support |
| Mono-color | Mono |
| S/n ratio | >39dB |
