Description
| Ordernumber | 108221 |
| Sensor shutter | Rolling Shutter |
| Sensor Type | CMOS |
| Resolution (horizontal) (pixels) | 3840 |
| Resolution (vertical) (pixels) | 2160 |
| Pixel Size (horizontal) (µm) | 2.1 |
| Pixel Size (vertical) (µm) | 2.1 |
| Pixel Depth (bits) | 20, more to follow |
| Synchronization | free-run,software trigger |
| In-Camera Image Preprocessing | Host processor (ISP) |
| Exposure Control | programmable via the camera API,automatic,manual |
| Digital Input | 2 |
| Digital Output | 2 |
| Power Requirements | 5V DC (via BCON for MIPI interface) |
| Power Consumption (typical) (W) | 0.6 |
| Housing | Board Level |
| Housing Size L (mm) | 29 |
| Housing Size W (mm) | 29 |
| Housing Size H (mm) | 17.5 |
| Weight (typical) (g) | 15 |
| Conformity | RoHS,CE,FCC,GenICam,MIPI CSI-2,UL,EAC,KC |
For more information about the features, visit the Basler Product Documentation.
