| Exposure time |
Exposure time
|
| Frame rate |
523fps (Mono 8bit)
|
| Gain |
MANUAL: 0 to +36dB, AGC: 0 to +24dB
|
| Image buffer |
256MB / 690 frames (all pixels readout)
|
| Interface |
USB3 Camera (Compact)
|
| Lens mount |
C-mount
|
| Mass |
approx. 33g
|
| Pixel size |
6.9μm x 6.9μm
|
| Power consumption |
2.2W max.
|
| Power supply |
DC5V ±5%
|
| Resolution |
720(H) x 540(V)
|
| Sensitivity |
2,800 lx (F5.6, 1/500s)
|
| Aspect ratio |
4:03
|
| Black level |
-25% to +25%
|
| Bu040m series |
30μs – 16s
|
| Color type |
B/W Camera
|
| Conformity |
CE, FCC, RoHS, WEEE, USB3 Vision, GenICam, IIDC2
|
| Electronic shutter method |
MANUAL: Global shutter / Random Trigger Shutter: Global shutter
|
| Exposure time2 |
MANUAL: 1.08μs to 13.31μs (Short exposure mode ON), 20μs to 16s (Short exposure mode OFF) AE: 20μs to 1s Random Trigger Shutter: 20μs to 16s (Edge or Bulk mode), 50μs to Trigger width (Level mode)
|
| External dimension |
29(W) x 29(H) x 16(D) mm (Not including protruding parts)
|
| External trigger input |
Low: 0 to 0.5V, High: 2 to 24.0V High active / Low active, Pulse width: 50μs (minimum)
|
| Gamma / lut |
γ=1.0 to 0.45 / In 12bit, Out 12bit
|
| Image output format |
Mono 8bit / Mono 10bit / Mono 12bit
|
| Image size |
1/2.9 type
|
| Imager |
CMOS image sensor
|
| Imager model |
IMX287LLR
|
| Interface3 |
USB 5Gbps (USB3.1 Gen1) (Only SuperSpeed is supported)
|
| Manual |
AE
|
| Minimum illuminance |
2 lx (F1.4, Gain: +36dB, Video level: 50%)
|
| Operation humidity |
10% to 90% (no condensation)
|
| Operation temperature |
0°C to 40°C (below 60°C on cabinet surface)
|
| Optical glass filter |
Dust-proof glass
|
| Pixels |
0.4M
|
| Random trigger shutter mode |
Edge / Level / Bulk (255 times)
|
| Random trigger shutter type |
External Trigger / Software Trigger
|
| Readout mode |
All pixel, Scalable, Binning, Decimation, Mirroring, Flip
|
| Scanning |
Progressive
|
| Scanning area |
4.97mm(H) x 3.73mm(V)
|
| Sequential shutter |
16 entries (max)
|
| Short time exposure mode off |
Short time exposure mode ON
|
| Synchronization system |
Internal / Bus (USB)
|
