Description
| Ordernumber (SAP-Number) | 2.200000269E9 |
| Framegrabbe Line | Acquisition |
| Framegrabbe Series | Basler |
| processor | Xilinx Ultrascale+ KU3P |
| On board memory | 1 GByte DDR4-RAM |
| Connectors | 1 x Micro-BNC/HD-BNC |
| Camera Support | area scan camera |
| Sensor Type | CFA sensor (Bayer),Grayscale sensor |
| Sensor Resolution | 32k*64k (area scan sensor) |
| Bit Depth | 8-16-bit (grayscale), 24-48-bit (color) |
| GPIO Interface Summary | Front GPIO: up to 3 differential signals in, up to 4 single-ended signals in (depends on configuration), 2 TTL outputs |
| Basic Features | ROI |
| Dimensions | PCIe Standard height, low profile card: 167.64 mm length x 68.9 mm height |
| Approximate Weight | 170 g |
| Power consumption / Power Source | Typ. 13,4W@12V, excluding camera and I/O power output |
| Operating Temperature | 0 – 50°C (32°F – 122°F) |
| Storage Temperature | -50 – 80°C (-58°F – 176°F) |
| Relative Humidity (operating, storage) | 5% – 90% non-condensing (operating), 0% – 95% (storage) |
| Compliances | WEEE,REACH,RoHS,CE class B,FCC class B |
| Software drivers | Windows 10 / 8 / 7 (32-Bit),Windows 10 / 8 / 7 (64-Bit),Linux 64-Bit |
| Software Tools | Documentation,Device Drivers,pylon Software Suite |
| Software API | pylon SDK |
| BV-Software Compatibility | pylon Software Suite |
| Cable length | <100 |
| Flexibility | Configurable |
| Number of Cameras | 1 |
| System Costs | Established |
For more information about the features, visit the Basler Product Documentation.
