AX5F57CP050E
AX5F57CP050E - Image 2
AX5F57CP050E - Image 3
AX5F57CP050E - Image 4
AX5F57CP050E - Image 5
AX5F57CP050E - Image 6
AX5F57CP050E - Image 7

AX5F57CP050E

Sensor GMAX3265
Image Sensor 29.9 mm × 22.4 mm CMOS
Shutter Global
Resolution 9344 × 7000
Frame Rate 71 fps
Bit Depth 10 bit
Mono/Color Color
Pixel Size 3.2 μm × 3.2 μm
Pixel 65 MP
S/N Ratio 40 dB
Dynamic Range 66 dB
Image Format BayerGB8/10/12
ROI Support
X Flip Support
Y Flip Support
Gain Analog gain: 1x ~ 4.8x, Digital gain: 1x ~ 100x
Exposure Time 27 μs ~ 5 s
Trigger Mode Software Trigger/Hardware Trigger/Free Run Mode
SPC Support
User Setting Support two sets of user-defined configurations
Port CXP-12
GPIO Interface 3x Opto-isolated input, 3x Opto-isolated output;1x RS232
Lens Mount M58 × 0.75
Power Supply DC 24V power supply via 12 Hirose interface, support PoCXP
Power Consumption 24 V ≈ 24 W
Product Dimensions 80 mm × 80 mm × 73.4 mm (Non including rear case connector)
Net Weight 790 g
Storage Temperature -30℃~+80℃
Operating Temperature -30℃~+50℃
Add to Quote
Category: Tag: Brand:

Description

  • CXP-12 interface, 4 x 12.5Gbps theoretical transfer bandwidth
  • Support hardware trigger/free run mode
  • Support pixel-by-pixel FFC function
  • Support multiple image data formats output, ROI and etc.；
  • Support PoCXP and DC 24V power supply
  • Conforms to CoaXPress protocol and GenICam standard
  • Conform to CE, KC and RoHS

Dimensions

Downloads

AX5F57CP050E_Datasheet_2025-10-17.pdf
CoaXPress_Area_Scan_Camera_User_s_Manual_V1.0.0.pdf
80×80×73_4-CXP12-M58-3D.rar
MVviewer_Ver2.4.2.26_Linux_x86_Build20250113.zip?response-content-disposition=attachment;filename=Machine%2BVision%2BMVviewer%2BClient%2BVer2.4.2.26%2528Linux%2Bx86%2529.zip

Additional information

Bit depth

10 bit
Dynamic range

66 dB
Exposure time

27 us ~ 5 s
Frame rate

71 fps
Gain

Analog gain: 1x ~ 4.8x, Digital gain: 1x ~ 100x
Gpio interface

3x Opto-isolated input, 3x Opto-isolated output；1x RS232
Image format

BayerGB8/10/12
Image sensor

29.9 mm x 22.4 mm CMOS
Lens mount

M58 x 0.75
Pixel

65 MP
Pixel size

3.2 um x 3.2 um
Port

CXP-12
Power consumption

24 V ≈ 24 W
Power supply

DC 24V power supply via 12 Hirose interface，support PoCXP
Resolution

9344 x 7000
Roi

Support
Sensor

GMAX3265
Shutter

Global
Spc

Support
Storage temperature

-30℃~+80℃
Trigger mode

Software Trigger/Hardware Trigger/Free Run Mode
User setting

Support two sets of user-defined configurations
X flip

Support
Y flip

Support
Mono-color

Color
S/n ratio

40 dB
