Description
| Ordernumber | 107655 |
| Sensor shutter | Global Shutter |
| Sensor Type | CMOS |
| Sensor width (mm) | 4.97 |
| Sensor height (mm) | 3.73 |
| Resolution (horizontal) (pixels) | 720 |
| Resolution (vertical) (pixels) | 540 |
| Pixel Size (horizontal) (µm) | 6.9 |
| Pixel Size (vertical) (µm) | 6.9 |
| Pixel Depth (bits) | 8/12 |
| Synchronization | hardware trigger,free-run,software trigger |
| Exposure Control | programmable via the camera API,hardware trigger |
| Digital Input | 1 |
| Digital Output | 1 |
| General Purpose I/O | 2 |
| Power Requirements | Via USB 3.0 interface |
| Power Consumption (typical) (W) | 3 |
| Housing | Box |
| Housing Size L (mm) | 29.3 |
| Housing Size W (mm) | 29 |
| Housing Size H (mm) | 29 |
| Housing Temperature min (°C) | 0 |
| Housing Temperature max (°C) | 50 |
| Weight (typical) (g) | 80 |
| Conformity | RoHS,FCC Class B,CE,IP30,GenICam,USB3 Vision,UL,KC,EAC |
For more information about the features, visit the Basler Product Documentation.
