Description
| Ordernumber | 106221 |
| Sensor shutter | Global Shutter |
| Sensor Type | CCD |
| Sensor width (mm) | 4.88 |
| Sensor height (mm) | 3.66 |
| Resolution (horizontal) (pixels) | 659 |
| Resolution (vertical) (pixels) | 494 |
| Pixel Size (horizontal) (µm) | 7.4 |
| Pixel Size (vertical) (µm) | 7.4 |
| Pixel Depth (bits) | 12 |
| Synchronization | hardware trigger,free-run,software trigger |
| Exposure Control | programmable via the camera API,hardware trigger |
| Digital Input | 1 |
| Digital Output | 1 |
| General Purpose I/O | 2 |
| Power Requirements | Via USB 3.0 interface |
| Power Consumption (typical) (W) | 2.7 |
| Housing | Box |
| Housing Size L (mm) | 29.3 |
| Housing Size W (mm) | 29 |
| Housing Size H (mm) | 29 |
| Housing Temperature min (°C) | 0 |
| Housing Temperature max (°C) | 50 |
| Weight (typical) (g) | 80 |
| EMVA Quantum Efficiency (typical) (%) | 42.95 |
| Dark Noise (typical) (e¯) | 12.4 |
| Saturation Capacity (typical) (ke¯) | 14.9 |
| Dynamic Range (typical) (dB) | 61.6 |
| Signal- to -Noise Ratio (dB) | 41.7 |
| Conformity | CE,RoHS,GenICam,IP30,UL,FCC,USB3 Vision,KC,EAC |
For more information about the features, visit the Basler Product Documentation.
