Description
| Ordernumber | 106755 |
| Sensor shutter | Global Shutter |
| Sensor Type | CMOS |
| Sensor width (mm) | 6.14 |
| Sensor height (mm) | 4.92 |
| Resolution (horizontal) (pixels) | 1280 |
| Resolution (vertical) (pixels) | 1024 |
| Pixel Size (horizontal) (µm) | 4.8 |
| Pixel Size (vertical) (µm) | 4.8 |
| Pixel Depth (bits) | 10 |
| Synchronization | hardware trigger,free-run,Ethernet connection |
| Exposure Control | programmable via the camera API,hardware trigger |
| Digital Input | 1 |
| Digital Output | 1 |
| General Purpose I/O | 1 |
| Power Requirements | PoE or 12-24 VDC |
| Power Consumption (typical) (W) | 3.5 |
| Power Consumption (PoE) (W) | 3.5 |
| Housing | Box |
| Housing Size L (mm) | 42 |
| Housing Size W (mm) | 29 |
| Housing Size H (mm) | 29 |
| Housing Temperature min (°C) | 0 |
| Housing Temperature max (°C) | 50 |
| Housing Alternatives | none |
| Weight (typical) (g) | 90 |
| EMVA Quantum Efficiency (typical) (%) | 55 |
| Dark Noise (typical) (e¯) | 10.7 |
| Saturation Capacity (typical) (ke¯) | 7.8 |
| Dynamic Range (typical) (dB) | 57.3 |
| Signal- to -Noise Ratio (dB) | 38.9 |
| Conformity | CE,RoHS,GenICam,GigE Vision,IP30,IEEE 802.3af (PoE),UL,KC,EAC |
For more information about the features, visit the Basler Product Documentation.
