Description
| Order number | 109260 |
| Shutter Mode | Global Shutter |
| Sensor Type | CMOS |
| Sensor size | 7.78 mm × 7.78 mm |
| Resolution (H x V) | 2840 px × 2840 px |
| Pixel size (H x V) | 2.74 ?m × 2.74 ?m |
| Spectrum | Visible |
| Pixel Depth(bit) | 8/10/12 |
| Synchronization | free-run,hardware trigger,software trigger |
| Exposure Control | programmable via the camera API,hardware trigger |
| Digital Input | 1 |
| General Purpose I/O | 2 |
| Power Requirements | PoCXP |
| House Type | Box |
| House size (L x W x H) | 29 mm x 29 mm |
| Weight | 76 g |
| Operating temperature | 0 °C – 50 °C |
| Conformity | CE (incl. RoHS), CoaXPress 2.0, EAC, GenICam, IP30, KC, UKCA, UL (in preparation) |
For more information about the features, visit the Basler Product Documentation.
