Description
| Ordernumber | 108429 |
| Sensor shutter | Global Shutter |
| Sensor Type | CMOS |
| Sensor width (mm) | 6.71 |
| Sensor height (mm) | 5.61 |
| Resolution (horizontal) (pixels) | 2448 |
| Resolution (vertical) (pixels) | 2048 |
| Pixel Size (horizontal) (µm) | 2.74 |
| Pixel Size (vertical) (µm) | 2.74 |
| Pixel Depth (bits) | 8/10/12 |
| Synchronization | free-run,hardware trigger,software trigger |
| Exposure Control | programmable via the camera API,hardware trigger |
| Digital Input | 1 |
| General Purpose I/O | 2 |
| Power Requirements | Via USB 3.0 interface or 12-24 VDC |
| Power Consumption (typical) (W) | 3.9 |
| Housing | Box |
| Housing Size L (mm) | 42.8 |
| Housing Size W (mm) | 29 |
| Housing Size H (mm) | 29 |
| Housing Temperature min (°C) | 0 |
| Housing Temperature max (°C) | 50 |
| Weight (typical) (g) | 90 |
| EMVA Quantum Efficiency (typical) (%) | 65.7 |
| Dark Noise (typical) (e¯) | 2.1 |
| Saturation Capacity (typical) (ke¯) | 9.6 |
| Dynamic Range (typical) (dB) | 70.9 |
| Signal- to -Noise Ratio (dB) | 39.8 |
| Conformity | RoHS,CE,IP30,FCC,GenICam,USB3 Vision,EAC,KC,UL |
For more information about the features, visit the Basler Product Documentation.
