Description
| Ordernumber | 107964 |
| Sensor shutter | Global Shutter |
| Sensor Type | CMOS |
| Sensor width (mm) | 6.6 |
| Sensor height (mm) | 4.1 |
| Resolution (horizontal) (pixels) | 1920 |
| Resolution (vertical) (pixels) | 1200 |
| Pixel Size (horizontal) (µm) | 3.45 |
| Pixel Size (vertical) (µm) | 3.45 |
| Framerate Compression Beyond (fps) | 100 |
| Pixel Depth (bits) | 8/10/12 |
| Synchronization | free-run,hardware trigger,software trigger |
| Exposure Control | programmable via the camera API,hardware trigger |
| Digital Input | 1 |
| General Purpose I/O | 2 |
| Power Requirements | PoE or 12-24 VDC |
| Power Consumption (typical) (W) | 3.8 |
| Housing | Box |
| Housing Size L (mm) | 55.5 |
| Housing Size W (mm) | 29 |
| Housing Size H (mm) | 29 |
| Housing Temperature min (°C) | 0 |
| Housing Temperature max (°C) | 50 |
| Weight (typical) (g) | 105 |
| Conformity | RoHS,CE,IP30,GigE Vision 2.0,FCC,GenICam,KC,EAC,UL |
For more information about the features, visit the Basler Product Documentation.
