Description
| Order number | 108808 |
| Shutter mode | Global Shutter |
| Sensor Type | InGaAs |
| Sensor width (mm) | 6.4 |
| Sensor height (mm) | 5.1 |
| Horizontal resolution (pixel) | 1280 |
| Vertical resolution (pixel) | 1024 |
| Pixel size (horizontális) (µm) | 5 |
| Pixel size (vertical) (µm) | 5 |
| Pixel depth (bit) | 8/10/12 |
| Synchronization | free-run,hardware trigger,software trigger |
| Exposure Control | programmable via the camera API,hardware trigger |
| Digital Input | 1 |
| General I/O Connectors | 2 |
| Electricity demand | Via USB 3.0 interface |
| House | Box |
| House Dimensions (length) (mm) | 42.8 |
| House Dimension (width) (mm) | 29 |
| House Dimension (height) (mm) | 29 |
| Minimum temperature | -10 |
| Maximum temperature | 60 |
| Typical Weight (g) | 85 |
| Conformity | CE,EAC,FCC,GenICam,IP30,KC,RoHS,UL,USB3 Vision |
For more information about the features, visit the Basler Product Documentation.
