Description
| Ordernumber | 106958 |
| Sensor shutter | Rolling Shutter |
| Sensor Type | CMOS |
| Sensor width (mm) | 5.7 |
| Sensor height (mm) | 4.28 |
| Resolution (horizontal) (pixels) | 2592 |
| Resolution (vertical) (pixels) | 1944 |
| Pixel Size (horizontal) (µm) | 2.2 |
| Pixel Size (vertical) (µm) | 2.2 |
| Pixel Depth (bits) | 8, 12 |
| Synchronization | free-run |
| Exposure Control | programmable via the camera API |
| Power Requirements | Via USB 3.0 interface |
| Power Consumption (typical) (W) | 1.3 |
| Housing | Box |
| Housing Size L (mm) | 28.2 |
| Housing Size (mm) | 38.8 |
| Housing Temperature min (°C) | 0 |
| Housing Temperature max (°C) | 50 |
| Weight (typical) (g) | 60 |
| Conformity | FCC Class B,CE,RoHS,GenICam,UL,USB3 Vision,KC,EAC |
For more information about the features, visit the Basler Product Documentation.
